DTH DRILLING RIG -KM610MTRCOMBI- Model Top drive drill rig is capable of drilling in different formations, such as a medium to hard rock by DTH unconsolidated / Alluvial formations using Air / Water / Water flush by rotary method, up to a depth of 610 Mtr(2000 Feet), under favorable drilling conditions, The following are the detailed specifications DTH Drilling Rig Machines. Drilling Diameter 6.5’’, 9’’, 10’’ 12’’ (Over Burden Drilling Depth 2000 Feet (610 Mtrs) Application Water Well Drilling Formation Soft / Medium / Hard Mast Hydraulic Cylinder With Pulley & Wire Rope Max. Pull Up Force – 15500 Kgs Max. Pull Down Force – 7500 Kgs Max. Pull Up Speed – 45 Meter/Minute Prime Mover Truck Engine As Per Customer Request Hydraulic system Max. Working Pressure 320 Kg/cm2 MAST Construction - Sturdy Structural Channel Pull Up Speed - 20 Mtrs/Min Pull Down Speed - 30 Mtrs/Min Pull Up Force - 20940 Kgfm Pull Down Force - 10680 Kgfm ROTATION SPEED - 0-120 Note : Due to continuous development all the above specifications are subject to change
